SIDE-BAR

A modular battery design that utilizes pod-functionality to serve multiple oil & volume categories with the same base unit.

• Magnetic pod connection with singular ecosystem compatibility
• Dual preheat options: blow from bottom or 2x pod insertion
• Polycarbonate body
• USB-C pass-through charging with 340mAh battery
• 3 voltage settings: 2.6v, 3.0v, 3.4v
• Digital display screen with voltage and battery life

• Pod Insertion + Activation: Display on
• Voltage Change (3x pod insertions) : Blue 2.6v, Yellow 3.0v, Red 3.4
• Low Battery: Bar display low and flashes 10 times
• Low Battery Protection: Display off
• Short Circuit: Display off if resistance is less than 0.8Ω
• Charging: USB-C, Battery bars illuminated
• Unplug: Display flashes 3 times

The Verano HYPHEN battery is compatible with Singular pods only.

BATTERY CELL CAPACITY

• 340mAh

OUTPUT VOLTAGE

• L-2.6V
• M-3.0V
• H-3.4V

POWER INPUT

• 5V

RESISTANCE

• Loads from 1.0Ω – 3.0Ω

CHARGING CURRENT

• 350mA +- 50mA

ACTIVATION TIME

• 0 – 10 Seconds


SHORT-CIRCUIT PROTECTION

• Device will not activate when load is less than 1.0Ω, the screen will light for 2 seconds. Device resets after draw is finished.

LI-ION BATTERY

• Cells meet the requirements for Li-ion batteries.

OVER USE PROTECTION

• Device deactivates after a 10 second draw activation. The LED light will blink 2 times. Device resets after draw is finished.

CELL CONTAINMENT

• The battery cell is sealed within a protective housing that prevents user access without causing permanent damage and shields it during use and transport.

OVERCHARGE PROTECTION

• If voltage exceeds 7v, device will cancel charging. OVP will withstand up to 28V before device deactivation is enabled.
